Official Product Specifications & Structural Sizing Guide
Guangzhou Heda Shelves Co., Ltd. provides European warehouse logistics managers, systems integrators, and distributors with fully documented technical datasheets. Our catalog details standard cold-rolled Q235B/Q355B structural sections, dynamic beam deflection limits according to EN 15512, and Euro pallet (1200 × 800 mm / 1200 × 1000 mm) aisle clearances.
Whether you require selective pallet racking, multi-tier rack-supported mezzanines, radio shuttle tracks, or heavy-duty cantilever systems, our catalog serves as a project design reference for tender documents and structural evaluations.
Warehouse Storage Equipment Specification Dossier
Format: PDF | Direct Factory Source | Version: 2026Verified Load Parameters
Beam deflection ratios (1/200), upright capacity metrics, and maximum compartment loadings cross-referenced with EN 15512 calculations.
Certified Quality Standards
Full documentation of CE certificate No. 2435-CPR-8605159, ISO 9001:2015 quality processes, and electrostatic powder coating finishes.
Standardized Layout Plans
Detailed CAD profile cross-sections, teardrop and diamond connection pitches, safety pins, column baseplate anchors, and frame configurations.
| Storage System Classification | Standard Section Sizes | Standard Finish | European Compliance Reference |
|---|---|---|---|
| Selective Pallet Racking | 80/90/100/120 mm Uprights; 80–160 mm Box Beams | RAL 5015 Blue / RAL 2004 Orange Powder Coat | EN 15512, EN 15620, CE Certified |
| Drive-In & Drive-Through | Heavy-duty Omega section columns, continuous guide rails | High-durability polyester powder coating | FEM 10.2.07 principles |
| Radio Shuttle Automation | Galvanized high-precision running tracks, 40–50 mm pitch | Pre-galvanized track & coated frames | EN 15512, Machinery Directive (Shuttle) |
| Rack-Supported Mezzanine | Multi-tier racking uprights, rolled steel C-section joists | Galvanized steel plank or perforated floor | Eurocode 3 structural steel design |
| Heavy Duty Cantilever | IPE structural steel columns & tapered arms | RAL industrial coating or hot-dip galvanized | DIN 18800 structural stability standards |
