Per EN 15620 and FEM 10.2.02 recommendations, a standard two-pallet bay for 1200 × 800 mm Euro pallets (entering on the 800 mm face) utilizes 1800 mm clear beam spans, providing 75 mm side and central clearances. For standard three-pallet bays, 2700 mm beams are specified. When handling 1200 × 1000 mm industrial pallets, standard beam lengths increase to 2300 mm (2 pallets) and 3300 mm (3 pallets), ensuring sufficient handling tolerances for counterbalance and reach truck operators.

Every commercial order ships with formal structural calculations signed off by structural engineers, certified accordance with EN 15512:2020 limit state analysis. We supply detailed static calculation dossiers, frame load-capacity charts, beam deflection formulas, assembly torque specifications for M12/M16 chemical floor anchors, and metallic load warning notices (EN 15635 compliance) to affix permanently to rack bay ends.

Q235B possesses a nominal yield strength of 235 MPa and is the global benchmark for light to medium-duty selective beams and secondary bracing. Q355B offers a yield strength of 355 MPa (approx. 51% higher tensile capability). For high-bay upright columns exceeding 8 meters in height, heavy-load cantilever arms, or seismic zone installations, utilizing Q355B allows for reduced wall thicknesses while maintaining structural stability under heavy P-Delta secondary moments.

Yes. Our engineering department runs full Finite Element Analysis (FEA) response spectrum models aligned with Eurocode 8 (EN 1998) or American ASCE 7 seismic hazard maps. For high seismic zones (PGA > 0.2g), we engineer heavy-duty ductile baseplates, reinforced anchor embedment depths, cross-aisle portal bracing, and enhanced upright column thicknesses to prevent premature local buckling under lateral inertial forces.

The concrete slab must be evaluated for concentrated point loads imparted by rack upright baseplates, which frequently exceed 40 to 120 kN per leg. Typically, a reinforced concrete slab of minimum C25/30 or C30/37 grade with a thickness of 180mm to 250mm is necessary. For standard wide aisle forklift traffic, floor flatness conforming to DIN 18202 Table 3 Line 3 or ASTM E1155 F-min 50 ensures safe reach truck operation without mast sway.

Standard fabrication lead times range from 15 to 25 days depending on total project tonnage and custom RAL color formulations. Maritime transit times from our Guangzhou port (Nansha/Huangpu) average: Southeast Asian ports 5-8 days; European gateway ports (Rotterdam, Hamburg, Valencia) 28-35 days; US West Coast 18-22 days; US East Coast 30-38 days. All shipments are packed on heavy-duty steel cradles with moisture-barrier film to prevent maritime corrosion.

Yes. Approximately 45% of our monthly 30,000-tonne capacity is dedicated to OEM and ODM contracts for racking manufacturers, distributors, and material handling systems integrators worldwide. We provide custom upright slotting punches (teardrop, diamond, 50mm, 75mm European pitch), customized brand labeling, private packaging, and proprietary beam connector profiles.

Forklift impact is the leading cause of racking structural degradation. We recommend outfitting every end-of-row frame with heavy-duty structural steel floor-mounted crash barriers (yellow RAL 1023). Individual front uprights in high-traffic cross aisles should feature wrap-around steel column guards or polymer shock-absorbing protectors. For safety over pedestrian thoroughfares, wire mesh safety decking and back-drop netting must be installed.
