Heavy Duty Warehousing Racking Systems
Product Description
Heavy Duty Pallet Rack Overview
URGO Heavy duty pallet rack is very cost-effective, providing high capacity storage and easy access to all pallets. It offers direct access to all pallets with great load flexibility. It installs quickly and adjusts easily to your specific needs.
At present, our all raw materials are from large domestic steel corps, ensuring stable quality. Combined with our technical advantages, we provide complete logistics storage systems for our clients.
Key Applications: Warehouse & logistics, food/drug distribution, petroleum/chemical plants, automotive distributors, big box retail hardware, and home improvement stores.
Column Section Size Categories:
Type 80
Type 85
Type 90
Type 100
Type 120
Type 140
Beam Height Classification by Structure:
- Rectangular Tube Beam: 60 / 80 / 100 / 120 mm
- C Shape Tube Beam: 80 / 100 / 120 / 140 mm
- Box Beam: 80 / 90 / 100 / 110 / 120 / 140 / 160 / 180 mm
- Corbel Box Beam: 80 / 90 / 100 / 110 / 120 / 140 / 160 mm
- P Type Box Beam: 76.2 / 80 / 101.6 / 110 / 114.3 mm
URGO Heavy Weight Pallet Rack Features:
✔ 01
100% accessibility to individual pallets
✔ 02
Easy picking at lower levels
✔ 03
Optimal storage density
✔ 04
Easily installed and repositioned
✔ 05
No special lift trucks required
Product Structure & Specifications
The structure of the URGO heavy duty pallet rack includes uprights and beams. According to actual pallet load capacities and warehouse dimensions, column and beam specifications are selected alongside required accessories.
Upright Frame Details:
- High load capacity up to 21,000 kg.
- Frames include all assembly elements: bracing, base plates, nuts & bolts.
- Finish: Blue epoxy powder coated (RAL 5012 / 5015 / 5017).
- Standard heights: From 2m to 11.5m.
- Adjustable pitch: 50mm or 75mm adjustability.
Column Profiles Specification:
| Column Specification (mm) | Thickness (mm) | Upright Loading Capacity (kg) |
|---|---|---|
| W80 x D60 | 1.8 - 2.0 | 4,000 - 6,000 KG |
| W85 x D67 | 1.8 - 2.3 | 7,500 - 12,500 KG |
| W90 x D60 | 1.8 - 2.5 | 8,000 - 10,000 KG |
| W90 x D70 | 1.8 - 2.5 | 10,000 - 12,000 KG |
| W100 x D70 | 2.0 - 2.5 | 11,000 - 14,000 KG |
| W120 x D95 | 2.3 - 3.0 | 17,000 - 21,000 KG |
Box Beam Profiles Loading Table:
| Specification (mm) | Beam Length (mm) & Corresponding Load Capacity (kg) | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| 1500 | 2000 | 2300 | 2500 | 2700 | 3000 | 3300 | 3600 | 3900 | |
| 80 x 50 x 1.5 | 3000 | 1740 | 1340 | 1160 | 1010 | - | - | - | - |
| 90 x 50 x 1.5 | 4080 | 2350 | 1800 | 1645 | 1345 | 1010 | 850 | - | - |
| 100 x 50 x 1.5 | - | 2960 | 2260 | 1930 | 1680 | 1380 | 1040 | - | - |
| 110 x 50 x 1.5 | - | - | 2640 | 2250 | 1950 | 1600 | 1340 | 1140 | - |
| 120 x 50 x 1.5 | - | - | 3200 | 2730 | 2358 | 1930 | 1518 | 1379 | - |
| 140 x 50 x 1.5 | - | - | - | 3868 | 3330 | 2720 | 2370 | 2020 | - |
| 160 x 50 x 1.5 | - | - | - | - | 4220 | 3690 | 2970 | 2600 | 2340 |
| 160 x 50 x 1.8 | - | - | - | - | - | 4400 | 3420 | 3020 | 2590 |
| 160 x 50 x 2.0 | - | - | - | - | - | 4130 | 4170 | 3320 | 2840 |
P Box Beam Profiles Loading Table:
| Specification (mm) | Beam Length (mm) & Corresponding Load Capacity (kg) | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| 1500 | 2000 | 2300 | 2500 | 2700 | 3000 | 3300 | 3600 | 3900 | |
| 100 x 50 x 1.5 | 4470 | 2512 | 1900 | 1610 | 1380 | 1120 | 920 | - | - |
| 110 x 50 x 1.5 | 5484 | 3085 | 2332 | 1974 | 1693 | 1371 | 1133 | 952 | - |
| 120 x 50 x 1.5 | - | 3910 | 2957 | 2503 | 2146 | 1738 | 1436 | 1207 | 1030 |
| 140 x 50 x 1.5 | - | 5722 | 4330 | 3662 | 3140 | 2543 | 2102 | 1766 | 1505 |
Main Spare Parts Profiles:
Optional Accessories
Packaging & Shipping
URGO Packaging and Shipping Are Your Cargo’s Safeguard.
We operate a dedicated professional logistics management team. High-grade packaging methods meet your personalized shipping plan. Every procedural step of transport logistics is executed under strict quality supervision, ensuring orders arrive securely within agreed timelines.
Company Information & Qualifications
Engineering Design & Installation Services
Custom Warehouse Storage Layout:
URGO provides an experienced logistics structural design team capable of calculating structural parameters and planning optimal warehouse space utilization.
URGO provides an experienced logistics structural design team capable of calculating structural parameters and planning optimal warehouse space utilization.
Experienced engineering personnel provide ongoing technical design, detailed quotations, and responsive assistance.
Optimized production processes mitigate risk, maximize utility, and yield long-term ROI.
Tailored industrial storage layout solutions deliver maximum operational efficiency and economic advantage.
Installation & Relocation Support:
Our experienced installation crews coordinate complete assembly, field realignment, and industrial relocation for warehousing structures and matching storage apparatus.
Service Quality Commitment:
Backed by over 15 years of manufacturing expertise, our systems feature robust raw materials and fabrication control, offering an industry-leading 10-year warranty coverage under standard operation.
Featured Industrial Racking Solutions
Frequently Asked Questions
Q: What advantages distinguish URGO from other racking suppliers?
- Prompt Quoting: Response with clear quotes provided within 12 hours.
- Efficient Production: Standard selective pallet racking manufactured in 15 days.
- Protective Packaging: High-grade wrapping and beam edge clips prevent surface friction.
- Extended Warranty: High standards back up to a 10-year manufacturer warranty.
Q: What payment terms are accepted?
1) Standard terms: 30% T/T advance payment, remainder settled prior to dispatch.
2) Irrevocable 100% L/C at sight.
2) Irrevocable 100% L/C at sight.
Q: Can I monitor the production status of my order?
Yes, progress updates and photographic logs across key manufacturing stages are shared to ensure full visibility through to shipment.
Q: What details are needed for a fast and accurate quotation?
Standard specifications include:
- Pallet Racking dimensions: Height × Depth × Length
- Number of beam levels
- Load carrying capacity per level
- Total quantity of storage bays required
Q: What if I do not have exact racking specifications?
Provide these warehouse details, and our technical department will determine the layout:
- Gross unit load weight per pallet
- Pallet dimension package details (Length × Width × Overall Height)
- Warehouse usable ceiling clearance and CAD blueprints (if accessible)
- Forklift access pathways and turning radius
Q: Do you provide installation and relocation guidance?
Yes, professional engineering installation teams are available to direct local racking setup, warehouse expansion, or structural relocation according to client operational requirements.
